Centering Vise Holder
Overview of Sample Holders Carbon Tabs Stage Adapters Stub Adapters Sample Preparation
Overview
Rave Scientific offers the EM-Tec CV1 large centering vise SEM sample holder. This holder provides a unique advantage. It keeps the sample always clamped in the center of the holder. Both vise clamp jaws simultaneously move away or to the center of the holder at the same time.
The EM-Tec CV1 large centering vise clamp includes two base plates on which the vise jaws can be re-positioned for optimum sample compatibility. The brass dual vise spindle is located underneath the base plates with knurled handles at both ends. The spindle can be operated from either side. One side includes a removable spindle extension to provide better grip when opening the centering vise. Made from vacuum grade aluminum and brass to provide dry lubrication. The vise jaws are mounted on the base with brass mounting screws.
Features of the EM-Tec CV1 large centering vise SEM sample holder are:
- Provides firm grip for large and heavy samples
- Automatically holds the sample in the center of the SEM stage.
- Easier navigation from the center of the SEM
- Position able vise jaws on the base plate for optimum sample compatibility.
- Standard stage clamps from 0 to 110mm
- Spindle extension can be removed to reduce overall size
- Optional extension base plates allow clamping from 0 to 155mm
- Standard vise jaws with triple grooved side and smooth side
- Optional vise jaw with single 120° groove for round sample
The EM-Tec CV1 entering vise is a heavy duty sample holder intended for use on SEMs with large chambers and stages with a stage travel distances of 80mm or more. With a spindle travel of 42mm and position able vise jaws the standard clamping ranges are 0-42mm, 34-78mm and 68-110mm. With the optional extension plate the additional clamping range are 102-144mm and 113-155mm.
Specifications of the EM-Tec CV1 large centering SEM sample holder
| Base plate size | 40x40mm (2x) |
|---|---|
| Vise jaw VC3 size | 12x40x6mm (2x) |
| Spindle travel | 42mm |
| Standard interspacing | 17mm |
| Standard clamping capacity | 0-110mm |
| Overall size closed | 106x40x34mm |
| Overall size open | 122x40x34mm |
| Extension plate size | 22.5x40mm (2x) |
| Extended interspacing | 11mm |
| Extended clamping capacity | 0-155mm |
| Overall extended size closed | 146x40x34mm |
| Overall extended size open | 167x40x34mm |
Product #
Price
$659.99 each
EM-Tec CV1 large centering vise with a clamping capacity from 0-110mm. Clamping size can be increased to 155mm with the optional EM-Tec CVE1 extension pIates. Includes two standard triple grooved/smooth clamping jaws which are positionable on the baseplate. The EM-Tec-CV1 centering vise can be operated from both sides; two knurled handles are provided. For ease of operation a removable spindle extension is include with the centering vise. Overall size closed is 106x40x34mm, overal size open is 122x40x34mm. M4 threaded hole in the base for Hitachi SEMs and the versatile EM-Tec stage SEM stage adapters.
Product #
Price
$646.65 each
EM-Tec CV1 large centering vise with a clamping capacity from 0-110mm.Clamping size can be increased to 155mm with the optional EM-Tec CVE1 extension pIates. Includes two standard triple grooved/smooth clamping jaws which are positionable on the baseplate. The EM-Tec-CV1 centering vise can be operated from both sides; two knurled handles are provided. For ease of operation a removable spindle extension is include with the centering vise. Overall size closed is 106x40x34mm, overal size open is 122x40x34mm. M4 threaded hole in the base for Hitachi SEMs and the versatile EM-Tec stage SEM stage adapters.
Product #
Price
$127.99 each
EM-Tec CVE1 extension plate set for the EM-Tec CV1 large centering vise. With the extension plate set , the clamping range can be increased to 155mm. The extension plate comprise multiple positions to mount the vise jaws. With the extension plates the EM-Tec CV1 centering vise overall size increases to 167x40x34mm. Supplied with brass mounting screws.
set/2
Product #
Price
$51.99 each
EM-Tec CVC1 standard triple grooved/smooth vise jaws include one side with triple shallow 90° grooves to improve clamping of smaller and/or round samples. The vise jaw can be mounted with the smooth side to avoid markings on the samples. The vise jaws can be mounted op top of each other to increase the double the height of the vise jaws to 24mm. Size of the EM-Tec CVC1 standard vise jaw is 12x40x6mm.
Product #
Price
$53.32 each
EM-Tec CVC2 single large 120 degrees groove vise jaw, 12x40x6mm.Em-Tec CVC2 optional single large 120° groove vise jaw to clamp larger round objects. Can be used instead of the standard jaw vise. If needed, two can be mounted op top of each other to increase the vise jaw height to 24mm. Size of the EM-Tec CVC2 single large 120° groove vise jaw is 12x40x6mm.
Product #
Price
$23.99 each
The EM-Tec conductive soft jaw lining kit for vise type SEM sample holders comprises a conductive neoprene rubber sheet with a conductive adhesive layer on one side. It is intended to hold more delicate samples and to prevent marring or damaging sensitive surfaces. The conductive medium soft rubber provides both a soft grip and a grounding path.
