Miltex Biopsy Punch with Plunger System

                                                                          Available from 1 to 4mm in Size


52 004640 out





 OVERVIEW



The Integra Miltex Biopsy punch with plunger system is high quality coring tool, designed to cut, core, punch and retrieve smaller samples of thin and soft materials such as paper, plastics, films, gels, tissues, fabric, cloth, paint and coatings. It is the ideal tool to cut smaller samples from larger sheets or films of softer materials for subsequent microscopy investigations and SEM/EDS analysis. There are 5 different coring diameters available: 1.0, 1.5, 2.0, 3.0 and 4 mm with a maximum coring depth of 7mm. Spring-loaded internal plunger ejection system with locking mechanism for secure removal and transfer of coring samples.



The Integra Miltex Biopsy punches with plunger system include:

  • Ribbed handle for secure grip
  • Ultra-sharp seamless stainless steel cutting tip
  • Plunger ejection system for easy removal of samples
  • Ready-to-use sterilized disposable punch
  • Color coded by size



The Biopsy punches with plunger system are intended as disposable coring tools. However, when cross- contamination between samples is not an issue, these robust coring tools are reusable after cleaning.

Cleaning tip: Clean the cutting tip after each sampling by coring clean filter paper, rinse with ethanol or remove dried artifacts with compressed air.



Specifications of the Integra Miltex Biopsy punches with plunger systems



Product #

Size

Blade Thickness

Colour

Blade material

Length

Coring D

Sterile

Unit

RS-MN-52-004610

Ø1.0 mm

0.14 mm

Violet

Stainless steel

105mm

7mm max

yes

Each

RS-MN-52-004615

Ø1.5 mm

0.14 mm

Yellow

Stainless steel

105mm

7mm max

yes

Each

RS-MN-52-004620

Ø2.0 mm

0.16 mm

Red

Stainless steel

105mm

7mm max

yes

Each

RS-MN-52-004630

Ø3.0 mm

0.16 mm

Pink

Stainless steel

105mm

7mm max

yes

Each

RS-MN-52-004640

Ø4.0 mm

0.16 mm

Green

Stainless steel

105mm

7mm max

yes

Each





Price

$7.99 each



Price

$14.65 each



Price

$7.99 each



Price

$7.99 each



Price

$7.99 each



Price

$7.99 each



Price

$7.99 each



Price

$35.99 each

set/5
